Master MA-8.1K Cludadwy AmpLlawlyfr Defnyddiwr Siaradwr Bluetooth LIFIED

1. Rhagymadrodd

Thank you for choosing the Master MA-8.1K Portable Amplified Bluetooth Speaker. This manual provides essential information for the safe and efficient operation of your device. Please read it thoroughly before use and retain it for future reference.

The Master MA-8.1K is designed to deliver powerful and clear audio, featuring versatile connectivity options including Bluetooth, USB, Micro SD, and auxiliary input. It also includes a microphone for karaoke or public address functions and TWS (True Wireless Stereo) technology for pairing with another compatible speaker.

2. Cynnyrch Drosview

2.1 Cynnwys Pecyn

Wrth ddadbocsio, gwnewch yn siŵr bod yr holl eitemau yn bresennol:

• Master MA-8.1K Cludadwy Amplied Siaradwr Bluetooth
• Meicroffon Wired
• Rheolaeth Anghysbell
• Addasydd Codi Tâl
• Cebl Ategol

Figure 2.1: Master MA-8.1K speaker and included accessories.

2.2 Rear Panel Controls and Ports

Familiarize yourself with the controls and connection ports located on the rear panel of the speaker.

Ffigur 2.2: Manwl view of the rear control panel.

• Slot Micro SD: Ar gyfer chwarae sain fileo gerdyn Micro SD.
• Porth USB: Ar gyfer chwarae sain files o yriant fflach USB.
• Knob Cyfrol: Adjusts the main speaker volume.
• Knob Trebl: Yn addasu'r allbwn sain amledd uchel.
• Knob Bas: Yn addasu'r allbwn sain amledd isel.
• Mewnbwn Cynorthwyol (AUX IN): Jac 3.5mm ar gyfer cysylltu dyfeisiau sain allanol.
• Microphone Input (MIC IN): 6.35mm jack for connecting the wired microphone.
• Knob Cyfaint Meicroffon: Yn addasu cyfaint y meicroffon.
• Newid Pwer: Yn troi'r siaradwr ymlaen neu i ffwrdd.
• Switsh Golau LED: Yn rheoli'r goleuadau LED integredig.
• Botwm Modd: Cycles through input modes (Bluetooth, USB, Micro SD, AUX).
• TWS Mode Button: Initiates True Wireless Stereo pairing.
• Record/Play Button: For recording microphone input or playing back recordings.
• Mic Priority Button: Lowers music volume when microphone is in use.

Figure 2.3: Key features highlighted on the rear panel.

3. Gosod

3.1 Gwefru'r Siaradwr

The speaker is equipped with a rechargeable battery. Before first use, fully charge the speaker for optimal performance.

1. Connect the charging adapter to the DC 5V input port on the rear panel.
2. Plygiwch yr addasydd i mewn i soced drydanol safonol.
3. Bydd y golau dangosydd gwefru yn goleuo. Ar ôl ei wefru'n llawn, gall y golau newid lliw neu ddiffodd, yn dibynnu ar y model.
4. A full charge provides approximately 5 hours of continuous music playback.

3.2 Pweru Ymlaen/Diffodd

Locate the Power Switch on the rear panel.

• To turn on: Flip the Power Switch to the 'ON' position. The display will light up.
• To turn off: Flip the Power Switch to the 'OFF' position.

4. Cyfarwyddiadau Gweithredu

4.1 Cysylltiad Bluetooth

Cysylltwch eich ffôn clyfar, tabled, neu ddyfais arall sy'n galluogi Bluetooth yn ddi-wifr.

1. Turn on the speaker. It will automatically enter Bluetooth pairing mode, indicated by a flashing 'BLUE' on the display and an audible prompt.
2. Ar eich dyfais, galluogwch Bluetooth a chwiliwch am y dyfeisiau sydd ar gael.
3. Select 'MA-8.1K' from the list of devices.
4. Once connected, the speaker will emit an audible confirmation, and the 'BLUE' indicator will stop flashing.
5. Gallwch nawr chwarae sain o'ch dyfais drwy'r siaradwr.

Paru 4.2 TWS (Stereo Di-wifr Gwirioneddol)

Pair two Master MA-8.1K speakers for a stereo sound experience.

1. Ensure both MA-8.1K speakers are turned on and in Bluetooth mode, but not yet connected to any device.
2. On one of the speakers (this will be the primary speaker), press and hold the 'TWS' button. The speaker will emit a pairing tone.
3. The primary speaker will search for the secondary speaker. Once connected, both speakers will emit a confirmation tone.
4. Now, connect your Bluetooth device to the primary speaker as described in Section 4.1. Audio will play in stereo through both speakers.

4.3 USB and Micro SD Playback

Chwarae sain fileyn uniongyrchol o yriant fflach USB neu gerdyn Micro SD.

1. Insert a USB flash drive into the USB port or a Micro SD card into the Micro SD slot on the rear panel.
2. The speaker will automatically switch to USB or Micro SD mode and begin playing audio files. If it does not, press the 'Mode' button until the correct mode is selected.
3. Defnyddiwch y rheolyddion chwarae (Chwarae/Saib, Trac Nesaf/Blaenorol) ar y siaradwr neu'r teclyn rheoli o bell i reoli'ch cerddoriaeth.

4.4 Mewnbwn Cynorthwyol (AUX MEWN)

Connect external audio devices using the 3.5mm auxiliary cable.

1. Connect one end of the 3.5mm auxiliary cable to the AUX IN port on the speaker.
2. Cysylltwch ben arall y cebl â'r jac clustffonau neu allbwn sain eich dyfais allanol.
3. Press the 'Mode' button on the speaker until 'AUX' mode is selected.
4. Play audio from your external device. Adjust volume on both the speaker and your device.

4.5 Defnyddio Meicroffon

Use the included wired microphone for karaoke or public address.

1. Plug the wired microphone into the MIC IN port on the rear panel.
2. Adjust the 'Microphone Volume' knob to your desired level.
3. To prioritize microphone audio over music, press the 'Mic Priority' button. This will temporarily lower the music volume when you speak into the microphone.

Figure 4.1: Wired microphone and remote control.

4.6 Swyddogaethau Rheoli o Bell

The remote control provides convenient access to various speaker functions.

• Pwer: Yn troi'r siaradwr ymlaen/i ffwrdd.
• Modd: Switches between input sources (Bluetooth, USB, Micro SD, AUX).
• Cyfrol +/-: Adjusts the main volume.
• Chwarae/Seibiant: Yn dechrau neu'n oedi wrth chwarae.
• Blaenorol/Nesaf: Yn neidio i'r trac blaenorol neu'r trac nesaf.
• EQ: Cycles through equalizer presets (if available).
• Tewi: Yn treiglo'r allbwn sain.
• Botymau Rhif: For direct track selection in USB/Micro SD mode.

4.7 Goleuadau LED

The speaker features integrated LED lights.

• Use the 'LED Light Switch' on the rear panel to turn the lights on or off.

Ffigur 4.2: Blaen view gyda goleuadau LED.

5. cynnal

Proper care ensures the longevity of your Master MA-8.1K speaker.

• Glanhau: Defnyddiwch frethyn meddal, sych i lanhau tu allan y siaradwr. Peidiwch â defnyddio glanhawyr sgraffiniol na thoddyddion.
• Storio: Storiwch y siaradwr mewn lle oer, sych i ffwrdd o olau haul uniongyrchol a thymheredd eithafol.
• Gofal Batri: Os ydych chi'n storio am gyfnodau hir, gwefrwch y batri bob 3-6 mis i gynnal ei iechyd.
• Amlygiad Dŵr: Nid yw'r siaradwr hwn yn dal dŵr. Osgowch ddod i gysylltiad â dŵr neu leithder gormodol.

6. Datrys Problemau

Cyfeiriwch at yr adran hon am broblemau cyffredin a'u datrysiadau.

7. manylebau

Detailed technical specifications for the Master MA-8.1K speaker.

Figure 7.1: Speaker dimensions.

8. Gwarant a Chefnogaeth

Am wybodaeth am warant a chymorth i gwsmeriaid, cyfeiriwch at y ddogfennaeth sydd wedi'i chynnwys gyda'ch pryniant neu cysylltwch â'r manwerthwr lle cafodd y cynnyrch ei gaffael. Cadwch eich prawf prynu ar gyfer unrhyw hawliadau gwarant.
