PawHut 2-In-1 Dog Bike Trailer & Stroller User Manual

Rhagymadrodd

Thank you for choosing the PawHut 2-In-1 Dog Bike Trailer and Stroller. This versatile product is designed to provide a safe and comfortable way to transport your pet, whether you're cycling or walking. Please read this manual thoroughly before assembly and use to ensure proper operation and the safety of your pet.

Gwybodaeth Diogelwch

• Always ensure your pet is securely harnessed inside the carrier before use. A safety harness is included for this purpose.
• Peidiwch â rhagori ar y pwysau uchaf a argymhellir o 20 kg.
• Ensure all wheels are properly attached and secured before each use.
• When using as a bike trailer, ensure the hitch connector is firmly attached to your bicycle's rear axle.
• The red flag and reflectors are for visibility. Always use them, especially in low light conditions.
• Be aware of the product's dimensions, especially its width (72.5 cm / 73 cm), when navigating doorways or narrow paths.
• Do not leave your pet unattended in the trailer/stroller.
• Regularly inspect the product for any signs of wear or damage. Do not use if damaged.
• This product is suitable for medium-sized dogs up to 20kg, with a body length less than 60 cm and shoulder height less than 40 cm.

Cynnwys Pecyn

Gwiriwch fod yr holl gydrannau yn bresennol cyn dechrau'r cydosod:

• Main Carrier Unit (1)
• Rear Inflatable Wheels (2)
• Universal Front Wheels (2)
• bar llaw (1)
• Bicycle Hitch Arm (1)
• Safety Flag (1)
• Llawlyfr Defnyddiwr (1)

Gosod a Chynulliad

Mae angen cydosod. Dilynwch y camau hyn yn ofalus:

1. Unfold the Main Carrier Unit: Carefully unfold the main fabric carrier until it is fully extended and the frame locks into place.


   Image: The main carrier unit in its assembled stroller configuration, ready for use.
2. Atodwch Olwynion Cefn: Insert the two large inflatable rear wheels into the designated slots on the back of the carrier frame until they click securely into place. Ensure they are firmly seated.
3. Attach Front Wheels (Stroller Mode): For stroller use, attach the two universal front wheels to the front axle. Ensure they swivel freely.
4. Attach Handlebar (Stroller Mode): Slide the handlebar into the receivers at the top rear of the carrier until it locks. Adjust to a comfortable height if adjustable.
5. Attach Bicycle Hitch Arm (Trailer Mode): For bike trailer use, attach the bicycle hitch arm to the front of the carrier. This arm will connect to your bicycle's rear axle. Ensure the connection is secure.


   Image: Detail of the hitch connector that attaches the trailer to a bicycle's rear wheel axle. Suitable for bicycle wheel diameters between 24" and 28".

6. Install Safety Flag: Insert the safety flag into its designated slot on the carrier for increased visibility.
7. Gwiriadau Terfynol: Before first use, double-check all connections, wheels, and locking mechanisms to ensure they are secure.

Cyfarwyddiadau Gweithredu

Using as a Dog Stroller

To use the unit as a stroller, ensure the universal front wheels are attached and the handlebar is in place. The bicycle hitch arm should be removed or secured out of the way.

• Open the front mesh door to allow your pet to enter.
• Secure your pet using the internal safety harness.
• Close the mesh door securely. The plastic curtain can be rolled down for wind protection.
• Push the stroller using the handlebar. The universal front wheels provide easy maneuverability.
• Always engage the wheel brakes when stationary.

Image: Demonstrates the product's dual functionality as both a pet stroller and a pet trailer.

Using as a Dog Bike Trailer

To use the unit as a bike trailer, ensure the bicycle hitch arm is attached to the carrier and securely connected to your bicycle's rear axle. The universal front wheels should be removed or locked in an upright position if they interfere. The handlebar can be folded down or removed.

• Connect the hitch arm to your bicycle's rear wheel axle. Ensure the connection is tight and secure.
• Place your pet inside and secure them with the internal safety harness.
• Close the mesh door.
• Ensure the safety flag is upright and visible.
• Proceed with caution, especially when turning or braking, as the trailer adds length and weight to your bicycle.

Image: A person riding a bicycle with the PawHut dog trailer attached, carrying a dog, demonstrating its use as a bike trailer.

Cynnal a chadw

• Glanhau: The fabric can be spot cleaned with a damp cloth and mild soap. Do not use harsh chemicals or abrasive cleaners. Allow to air dry completely before folding or storing.
• Gofal Olwynion: Regularly check tire pressure on the inflatable rear wheels. Keep wheels clean and free of debris.
• Storio: For compact storage, the product features a foldable design with quick-release wheels. Remove the rear wheels and front wheels (if attached), fold the main unit flat, and store in a dry, cool place away from direct sunlight.


  Image: The dog trailer folded flat with its quick-release wheels and hitch arm detached, illustrating its compact storage capability.
• Arolygiad: Periodically inspect all parts for wear, tear, loose fasteners, or damage. Replace any worn or damaged parts immediately.

Datrys problemau

Manylebau

Image: A detailed diagram illustrating the various dimensions of the PawHut dog trailer and stroller in both configurations.

Image: Visual guide indicating suitable dog breeds and a diagram for measuring pet body length and shoulder height to ensure compatibility with the trailer.

Gwarant a Chefnogaeth

Am wybodaeth am y warant neu gymorth technegol, cyfeiriwch at y ddogfennaeth brynu neu cysylltwch â'ch manwerthwr. Cadwch eich prawf prynu ar gyfer unrhyw hawliadau gwarant.

Gwneuthurwr: Sold by MHSTAR (as per product data)

For further assistance, please visit the official PawHut store or contact their customer service.
